Samsung Electronics Envisions Hyper-Growth in Memory and Logic Semiconductors Through Intensified Industry Collaborations at Samsung Tech Day 2022Share open/close
A new wave of memory solutions and limitless partnership opportunities to bring greater capabilities to data center, server, mobile, gaming and automotive markets
The System LSI Business emphasizes its role as a ‘total solution’ fabless that can optimize solutions for customers through convergence of its wide-range product lineup
Samsung Electronics, a world leader in advanced semiconductor technology, today showcased a series of cutting-edge semiconductor solutions set to drive digital transformation through the decade, at Samsung Tech Day 2022. An annual conference since 2017, the event returned to in-person attendance at the Signia by Hilton San Jose hotel after three years.
This year’s event, attended by more than 800 customers and partners, featured presentations from Samsung’s Memory and System LSI business leaders — including Jung-bae Lee, President and Head of Memory Business; Yong-In Park, President and Head of System LSI Business; and Jaeheon Jeong, Executive Vice President and Head of Device Solutions (DS) Americas Office — on the company’s latest advancements and its vision for the future.
System LSI Business Highlights
In the morning session of this year’s Tech Day, the System LSI Business emphasized its goal of becoming a ‘total solution fabless’ through maximizing the synergy between its unique and wide-range product lineup. As Samsung Electronics’ fabless IC design house, the System LSI Business currently offers around 900 products, which include SoC (System on Chip), image sensor, modem, display driver IC (DDI), power management IC (PMIC) and security solutions.
The System LSI Business not only makes leading individual products, but is also a total solution provider that can merge the various logic technologies into one platform, in order to deliver optimized solutions to customers.
“In an age that requires machines to learn and think as people do, the importance of logic chips, which play the roles of the brain, heart, nervous system and eyes, is growing to unprecedented levels,” said Yong-In Park, President and Head of System LSI Business at Samsung Electronics. “Samsung will converge and combine its technology embedded in various products like SoC, sensor, DDI and modem, in order to lead the Fourth Industrial Revolution as a total solution provider.”
A Vision of Chips With Human-Like Performance
The Fourth Industrial Revolution was a key theme in System LSI’s Tech Day sessions. The System LSI Business’ logic chips are crucial physical foundations of Hyper-Intelligence, Hyper-Connectivity and Hyper-Data, which are the key areas of the Fourth Industrial Revolution. Samsung Electronics aims to enhance the performance of these chips to a level at which they can carry out human tasks just as well as people can.
With this vision in mind, the System LSI Business is focusing on improving the performance of its essential IP like NPU (Neural Processing Unit) and modem, as well as innovating CPU (Central Processing Unit) and GPU (Graphics Processing Unit) technology by collaborating with global industry leading companies.
The System LSI Business is also continuing its work on ultra-high resolution image sensors so that its chips can capture images as the human eye does, and also has plans for sensors that can play the role of all five of the human senses.
Next-Generation Logic Chips Showcased
Samsung Electronics revealed a number of advanced logic chip technology for the first time at the Tech Day booth, including 5G Exynos Modem 5300, Exynos Auto V920 and QD OLED DDI, which are essential parts of various industries such as mobile, home appliance and automotive.
Chips that were newly released or announced this year including the premium mobile processor Exynos 2200 were also on display, along with the 200MP ISOCELL HP3 — the image sensor with the industry’s smallest 0.56-micrometer (μm)-pixels. Built on the most advanced 4-nanometer (nm) EUV (extreme ultraviolet lithography) process and combined with cutting-edge mobile, GPU and NPU technology, the Exynos 2200 provides the finest experience for smartphone users. The ISOCELL HP3, with a 12 percent smaller pixel size than the predecessor’s 0.64μm, can enable an approximately 20 percent reduction in camera module surface area, allowing smartphone manufacturers to keep their premium devices slim.
Samsung showcased its ISOCELL HP3 in action by showing the attendees of Tech Day the picture quality of photographs taken with a 200MP sensor camera, as well as demonstrating the workings of System LSI’s fingerprint security IC for biometric payment cards that combines a fingerprint sensor, Secure Element (SE) and Secure Processor, adding an extra layer of authentication and security in payment cards.
Memory Business Highlights
In a year marking 30 years and 20 years of leadership in DRAM and NAND flash memory respectively, Samsung unveiled its fifth-generation 10nm-class (1b) DRAM as well as eighth- and ninth-generation Vertical NAND (V-NAND), affirming the company’s commitment to continue providing the most powerful combination of memory technologies over the next decade.
Samsung also emphasized how the company will demonstrate greater resilience through collaborative partnerships in the face of new industry challenges.
“One trillion gigabytes is the total amount of memory Samsung has made since its beginning over 40 years ago. About half of that trillion was produced in the last three years alone, indicating just how fast digital transformation is progressing,” said Jung-bae Lee, President and Head of Memory Business at Samsung Electronics. “As advances in memory bandwidth, capacity and power efficiency enable new platforms and these, in turn, stimulate more semiconductor innovations, we will increasingly push for a higher level of integration on the journey toward digital coevolution.”
DRAM Solutions to Advance Data Intelligence
Samsung’s 1b DRAM is currently under development with plans for mass production in 2023. To overcome challenges in DRAM scaling beyond the 10nm range, the company has been developing disruptive solutions in patterning, materials and architecture, with technology like High-K material well underway.
The company then highlighted upcoming DRAM solutions such as 32Gb DDR5 DRAM, 8.5Gbps LPDDR5X DRAM and 36Gbps GDDR7 DRAM that will bring new capabilities to data center, HPC, mobile, gaming and automotive market segments.
Expanding beyond conventional DRAM, Samsung also underscored the importance of tailored DRAM solutions such as HBM-PIM, AXDIMM and CXL that can fuel system-level innovation in better handling the explosive growth of data worldwide.
1,000+ V-NAND Layers by 2030
Since its inception a decade ago, Samsung’s V-NAND technology has progressed through eight generations, bringing 10 times the layer count and 15 times the bit growth. Samsung’s most recent, 512Gb eighth-generation V-NAND features a bit density improvement of 42%, attaining the industry’s highest bit density among 512Gb triple-level cell (TLC) memory products to date. The world’s highest capacity 1Tb TLC V-NAND will be available to customers by the end of the year.
The company also noted that its ninth-generation V-NAND is under development and slated for mass production in 2024. By 2030, Samsung envisions stacking over 1,000 layers to better enable data-intensive technologies of the future.
As AI and big data applications drive the need for faster and higher-capacity memory, Samsung will continue to leapfrog bit density by accelerating the transition to quad-level cell (QLC), while further enhancing power efficiency in support of more sustainable customer operations worldwide.
More Far-Reaching Solutions Amidst Greater Collaboration
Samsung introduced an extensive portfolio of storage solutions spanning data center, enterprise server, mobile, client, consumer and automotive applications. The company highlighted its high-performance, low-power computational storage optimized for AI and how it can contribute to eco-conscious computing. Samsung also presented a new DRAM-less SSD, the PM9C1a, which supports both PCIe 4.0 and 5.0.
Samsung then shared aggressive plans to lead the industry in intelligent mobility solutions. The company discussed its wide-ranging memory offerings designed for every modern automotive function, from in-vehicle infotainment (IVI), autonomous driving (AD) and advanced driver assisted systems (ADAS), clusters and gateways to telematics. Since entering the automotive memory market in 2015, Samsung has been rapidly growing its market presence with the intent of becoming the largest automotive memory provider by 2025.
Reaffirming its overriding goals of enhancing customer value and pursuing a customer-oriented development philosophy, Samsung stressed its intent to further expand its ecosystem partnerships. To stimulate more widespread open innovation, Samsung revealed a key element of its blueprint for greater customer collaboration. The company will open a Samsung Memory Research Center (SMRC) where customers and partners can test and verify Samsung memory and software solutions in various server environments. Beginning with the opening of its first SMRC in Korea in the fourth quarter of this year, Samsung plans to later launch additional hubs in the U.S. and around the world, in collaboration with ecosystem partners like Red Hat and Google Cloud.
